Technical Data & Specifications :
Complete Data Sheet :
Print :
Part No |
Inductance L (nH) |
fL (MHz) |
Tol ± (%) |
Q min |
fQ (MHz) |
SRF typ (GHz) |
DCR max (Ω) |
Rated DC Current (A) |
Get Sample |
0402AQC-0N9M-YY |
0.9 |
100 |
20 |
24 |
250 |
18 |
0.015 |
3.00 |
|
0402AQC-1N6K-YY |
1.6 |
100 |
10 |
24 |
250 |
18 |
0.040 |
2.00 |
|
0402AQC-2N8K-YY |
2.8 |
100 |
10 |
27 |
250 |
13.5 |
0.040 |
2.00 |
|
0402AQC-2N9K-YY |
2.9 |
100 |
10 |
27 |
250 |
12.5 |
0.040 |
2.00 |
|
0402AQC-3N0K-YY |
3.0 |
100 |
10 |
30 |
250 |
12.5 |
0.040 |
2.00 |
|
0402AQC-3N3K-YY |
3.3 |
100 |
10 |
30 |
250 |
14.0 |
0.040 |
2.00 |
|
0402AQC-3N6K-YY |
3.6 |
100 |
10 |
30 |
250 |
10.0 |
0.040 |
2.00 |
|
0402AQC-3N9K-YY |
3.9 |
100 |
10 |
32 |
250 |
10.0 |
0.040 |
2.00 |
|
0402AQC-4N3K-YY |
4.3 |
100 |
10 |
32 |
250 |
9.60 |
0.060 |
1.80 |
|
0402AQC-4N7K-YY |
4.7 |
100 |
10 |
31 |
250 |
8.00 |
0.050 |
1.85 |
|
0402AQC-5N1K-YY |
5.1 |
100 |
10 |
31 |
250 |
8.00 |
0.050 |
1.85 |
|
0402AQC-5N6K-YY |
5.6 |
100 |
10 |
31 |
250 |
8.00 |
0.050 |
1.85 |
|
0402AQC-5N9K-YY |
5.9 |
100 |
10 |
31 |
250 |
8.00 |
0.050 |
1.85 |
|
0402AQC-6N2K-YY |
6.2 |
100 |
10 |
31 |
250 |
8.00 |
0.050 |
1.80 |
|
0402AQC-6N8J-YY |
6.8 |
100 |
5 |
30 |
250 |
7.00 |
0.065 |
1.70 |
|
0402AQC-7N2J-YY |
7.2 |
100 |
5 |
31 |
250 |
7.00 |
0.065 |
1.70 |
|
0402AQC-7N5J-YY |
7.5 |
100 |
5 |
31 |
250 |
7.00 |
0.065 |
1.70 |
|
0402AQC-8N2J-YY |
8.2 |
100 |
5 |
30 |
250 |
6.50 |
0.065 |
1.65 |
|
0402AQC-8N7J-YY |
8.7 |
100 |
5 |
30 |
250 |
6.50 |
0.070 |
1.50 |
|
0402AQC-9N0J-YY |
9.0 |
100 |
5 |
30 |
250 |
6.50 |
0.078 |
1.50 |
|
0402AQC-9N1J-YY |
9.1 |
100 |
5 |
30 |
250 |
6.50 |
0.078 |
1.50 |
|
0402AQC-9N2J-YY |
9.2 |
100 |
5 |
30 |
250 |
6.00 |
0.078 |
1.50 |
|
0402AQC-9N5J-YY |
9.5 |
100 |
5 |
30 |
250 |
6.00 |
0.080 |
1.50 |
|
0402AQC-010J-YY |
10 |
100 |
5 |
30 |
250 |
6.00 |
0.080 |
1.50 |
|
0402AQC-011J-YY |
11 |
100 |
5 |
30 |
250 |
6.00 |
0.080 |
1.50 |
|
Standard Tolerance
Refer to table
Engineer's Kits
EK-0402AQC-X
Remarks
Refer to Complete Data Sheet for detailed information.
Packing Standard
Taped / Reel |
1000 [-08] |
5000 [-01] |
