Technical Data & Specifications :
Complete Data Sheet :
Print :
| Part No |
Inductance
L (µH) |
fL
(MHz) |
Tol
± (%) |
SRF
min
(MHz) |
DCR
max
(Ω) |
Rated DC Current (A) |
Get Sample |
| | sat |
| ΔT = 40°C |
| PISR-1R0M-04 |
1.0 |
0.1 |
20 |
164 |
0.009 |
21 |
8.6 |
|
| PISR-1R5M-04 |
1.5 |
0.1 |
20 |
160 |
0.007 |
16 |
7.4 |
|
| PISR-2R2M-04 |
2.2 |
0.1 |
20 |
95 |
0.014 |
14 |
7.1 |
|
| PISR-3R3M-04 |
3.3 |
0.1 |
20 |
72 |
0.017 |
15 |
6.4 |
|
| PISR-4R7M-04 |
4.7 |
0.1 |
20 |
70 |
0.020 |
12 |
5.5 |
|
| PISR-5R6M-04 |
5.6 |
0.1 |
20 |
41 |
0.022 |
12 |
5.5 |
|
| PISR-6R8M-04 |
6.8 |
0.1 |
20 |
35 |
0.029 |
10 |
4.7 |
|
| PISR-100M-04 |
10 |
0.1 |
20 |
24 |
0.029 |
10 |
4.5 |
|
| PISR-150M-04 |
15 |
0.1 |
20 |
20 |
0.035 |
8 |
4.1 |
|
| PISR-220M-04 |
22 |
0.1 |
20 |
15 |
0.04 |
7 |
3.6 |
|
| PISR-330M-04 |
33 |
0.1 |
20 |
10 |
0.06 |
5.6 |
3.1 |
|
| PISR-470M-04 |
47 |
0.1 |
20 |
8 |
0.07 |
4.6 |
2.7 |
|
| PISR-680M-04 |
68 |
0.1 |
20 |
6.5 |
0.10 |
3.6 |
2.3 |
|
| PISR-820M-04 |
82 |
0.1 |
20 |
6.0 |
0.15 |
3.1 |
1.9 |
|
| PISR-101M-04 |
100 |
0.1 |
20 |
5.2 |
0.17 |
3.1 |
1.9 |
|
| PISR-151M-04 |
150 |
0.1 |
20 |
4.2 |
0.22 |
2.6 |
1.6 |
|
| PISR-221M-04 |
220 |
0.1 |
20 |
3.3 |
0.34 |
2.2 |
1.3 |
|
| PISR-271M-04 |
270 |
0.1 |
20 |
3.0 |
0.52 |
1.9 |
1.1 |
|
| PISR-331M-04 |
330 |
0.1 |
20 |
2.7 |
0.52 |
1.9 |
1.1 |
|
| PISR-471M-04 |
470 |
0.1 |
20 |
2.1 |
0.76 |
1.4 |
0.85 |
|
| PISR-681M-04 |
680 |
0.1 |
20 |
1.8 |
1.10 |
1.2 |
0.74 |
|
| PISR-102M-04 |
1000 |
0.1 |
20 |
1.3 |
1.70 |
1.0 |
0.57 |
|
| PISR-332M-04 |
3300 |
0.1 |
20 |
0.76 |
5.50 |
0.40 |
0.40 |
|
| PISR-472M-04 |
4700 |
0.1 |
20 |
0.76 |
7.20 |
0.35 |
0.22 |
|
| PISR-103M-04 |
10000 |
0.1 |
20 |
0.55 |
18.5 |
0.25 |
0.20 |
|
Material
Core : Ferrite, Base : Plastic
Standard Tolerance
Refer to table.
