Chip Inductors for RF Applications (Wire wound - open)

0302AS New!

Technical Data & Specifications :

Complete Data Sheet :

Print :


Part No Inductance
L (nH)		 fL
(MHz)		 Tol
± (%)		 Q
typ
@ 900 MHz		 Q
typ
@ 1.7 GHz		 Q
typ
@ 2.4 GHz		 SRF
typ
(GHz)		 DCR
max
(Ω)		 Rated
DC Current
(A)		 Get Sample
0302AS-1N2K-YY 1.2 250 10 50 80 100 16.10 0.045 1.40
0302AS-1N7K-YY 1.7 250 10 50 75 95 16.10 0.045 1.20
0302AS-1N9K-YY 1.9 250 10 50 70 95 16.00 0.055 1.20
0302AS-2N1K-YY 2.1 250 10 45 65 90 15.90 0.065 1.20
0302AS-3N0K-YY 3.0 250 10 45 60 90 15.10 0.065 1.00
0302AS-3N3K-YY 3.3 250 10 43 60 90 11.50 0.065 1.00
0302AS-3N5K-YY 3.5 250 10 43 60 90 11.50 0.075 1.00
0302AS-3N9K-YY 3.9 250 10 40 60 90 10.60 0.085 1.00
0302AS-4N7K-YY 4.7 250 10 40 60 90 12.00 0.090 0.80
0302AS-5N6K-YY 5.6 250 10 40 60 80 6.40 0.100 0.75
0302AS-6N3K-YY 6.3 250 10 40 60 75 9.30 0.110 0.70
0302AS-6N5K-YY 6.5 250 10 40 60 70 8.10 0.115 0.70
0302AS-7N2K-YY 7.2 250 10 40 60 70 9.10 0.115 0.70
0302AS-7N4K-YY 7.4 250 10 40 60 70 7.90 0.115 0.70
0302AS-011J-YY 11 250 5 40 55 60 6.85 0.150 0.65
0302AS-018J-YY 18 250 5 32 45 45 6.00 0.320 0.45
0302AS-019J-YY 19 250 5 32 45 45 5.79 0.350 0.40
Material
Ceramic
Standard Tolerance
Refer to table
Engineer's Kits
EK-302AS-X
Packing Standard
Taped / Reel
1000 [-08]
5000 [-01]
