Chip Inductors for RF Applications (Wire wound - open)

Technical Data & Specifications :

Complete Data Sheet :

Print :

Part No	Inductance L (µH)	fL (MHz)	Tol ± (%)	DCR max (Ω)	Isat typ (A)	Isat max (A)	Irms typ (A)	Irms max (A)
0603LDM-1R0X-01	1.0	1.0	20,30	0.192	1.90	1.50	1.80	1.50
0603LDM-2R2X-01	2.2	1.0	20,30	0.288	1.50	1.20	1.40	1.20
0603LDM-4R7X-01	4.7	1.0	20,30	0.600	1.00	0.80	0.90	0.80
0603LDM-6R8X-01	6.8	1.0	20,30	0.960	0.80	0.60	0.63	0.56
0603LDM-100X-01	10	1.0	20,30	1.260	0.70	0.56	0.63	0.56

Material

Ferrite

Standard Tolerance

Engineer's Kits

EK-0603LDM-X

Packing Standard

Taped / Reel
4000 [-01]
